THERMAL MODULE SPECIFICATIONS
| IMAGE SENSOR | VOx Uncooled Focal Plane Arrays | |
| MAXIMUM RESOLUTION | 640 × 512 | |
| FRAME RATE | 25 Hz | |
| PIXEL INTERVAL | 12 μm | |
| NETD | ＜20mk (@25°C,F#=1.0) | |
| LENS (FOCAL LENGTH) | 50 mm | |
| DETECTION RANGE | 2600 m | |
| FOCUS MODE | Manual | |
| FIELD OF VIEW (H X V) DEGREES / M @ 100M | 8.8 ° × 7.0 ° （H × V）/ 15.4 m × 12.2 m | |
| MINIMUM FOCUSING DISTANCE | 5 m | |
| APERTURE | F 0.9 | |
| MAGNIFICATION | 3.4 × | |
| DIGITAL ZOOM | 1 ×, 2 ×, 4 ×, 8 ×, 16 × |
OPTICAL MODULE SPECIFICATIONS
|
IMAGE SENSOR |
1.88'' Progressive Scan CMOS | |
| MAXIMUM RESOLUTION | 2560 x 1440 | |
| MINIMUM RESOLUTION | 0.001 lux @ (F1.0 , AGC On) | |
| FOCAL LENGTH | 31 mm | |
| IMAGE ENHANCEMENT | YES | |
| APERTURE | F 1.2 | |
| IR ILLUMINATOR WAVELENGTH | 940nm | |
| VIEWING RANGE AT NIGHT | 350 m | |
| SMART IT | YES |
IMAGE DISPLAY SPECIFICATIONS
|
DISPLAY |
0.39 inch, OLED, 1024 ×768 | |
| FFC (FLAT FIELD CORRECTION) MODE | Auto, Manual, External Correction | |
| IMAGE MODE | Optical、Fusion、White Hot、Black Hot、Red Hot、Image Fusion | |
| DIOPTER (RANGE) | -5 D to +3 D | |
| OPTICAL MODE | Day、Night、Auto、Defog | |
| IMAGE PRO | YES |
GENERAL SPECIFICATIONS
|
PROTECTION LEVEL |
IP67 | |
| WEIGHT | 1120 g | |
| DIMENSION | 217.5 mm × 155.0 mm × 87.5mm | |
| ACCESSORY | Battery Charger, Power Cable, Lens Cloth, Two Wrist Straps, Neck Strap, Quick Start Guide, Six Batteries, Adaptor, Carrying Case | |
| WORKING TEMPERATURE | -30 °C to 55 °C | |
| WORKING HUMIDITY | <90% | |
| STORAGE TEMPERATURE | -40 °C to 70 °C | |
| EYE-RELIEF | 15 mm | |
| INTERPUPILLARY ADJUSTMENT RANGE | 60 mm to 70 mm | |
| MOUNTING ADAPTER | 1/4“-20-UNC |
SYSTEM SPECIFICATIONS
| BUILT-IN MEMORY | 64 GB | |
| RECORD VIDEO | MP4 , 1600 × 1200 | |
| CAPTURE SNAPSHOT | JPEG , 1600 × 1200 | |
| HOTSPOT | Yes | |
| GPS | Yes | |
| DIGITAL MAGNETIC COMPASS | Yes | |
| STANDBY MODE | Yes | |
| PIP | Yes | |
| HOT TRACK | Yes | |
| AUDIO RECORDING | Yes | |
| PROXIMITY SENSOR | Yes | |
| MULTIPLE LANGUAGE | Yes | |
| LOCAL ALBUM | Yes | |
| SUPPORTED APPLICATION | HIKMICRO Sight |
POWER SUPPLY SPECIFICATIONS
| BATTERY TYPE | Replaceable and Rechargeable Li-ion Battery | |
| BATTERY OPERATING TIME | 8 hours continuous running with hotspot function off (@25°C) | |
| TYPE-C POWER SUPPLY |
Yes |
LASER RANGE FINDER SPECIFICATIONS
|
SAFETY CLASS FOR LASER |
Class 1 | |
| WAVELENGTH | 905 nm | |
| MAXIMUM MEASURING DISTANCE | 1000 m | |
| MEASUREMENT ACCURACY | ± 1 m |
