FEATURES
Rule the Night, Tame the Wild
The ACE series of thermal riflescopes feature a self-developed high-resolution thermal sensor, integrated LRF, and advanced Reality+ and Vision+ systems. Deliver unparalleled image quality and superior performance.
- 1280x1024 Thermal Sensor
- Vision + System
- Integrated LRF
- Ocular Zoom
- R+ AI Image Algorithm
- 3100m Detection Range
Superior Sensor Ensures Excellence
Equipped with a Gen-2 HD thermal sensor offering a resolution of up to 1280×1024 and a frame rate of up to 60Hz, the ACE provides stable performance with an NETD≤15mK. This enables it to detect even the slightest temperature variations, delivering exceptionally detailed and smooth thermal imagery, even when tracking fast-moving prey.
- Gen-2 HD
- 1280x1024, 12μm
- NETD≤15mK
- 50-60Hz
Enhanced Clarity with Larger Lens
The ACE series feature 60mm/F1.0 or 50mm/F0.9 lenses. The larger objective lens allows 20% more light to reach the sensor. Coupled with high-transmittance lens elements, it generates brighter and clearer images.
Long-Distance Detection at Ease
The ACE series boasts an impressive detection range of up to 3100 meters. This capability allows clear identification of distant targets, providing a significant advantage for long-range hunting.
- 3100m Detection Range
Reality+ Imaging Enhancement
Our proprietary Reality+ image processing algorithm effectively eliminates environmental temperature noise, enhancing contrast and detail clarity
New Vision+ System with Ocular Zoom
The new Vision+ system features a 1.03-inch, round, 2560×2560 AMOLED screen and industry-leading ocular zoom for direct optical magnification. Unlike traditional e-zoom, it prevents blurring and distortion in close-up views. Enjoy high-resolution images and a broader field of view for an immersive and comfortable observation experience.
Agile and Precise Built-in LRF
The ACE is equipped with an integrated LRF, offering laser range-finding up to 1200 meters with true optical axis alignment, ensuring precise distance measurements while maintaining a sleek and elegant design.
- S60R & H50R Only
Eliminate Battery Capacity Concerns
The ACE employs a dual-battery system with a 4000mAh built-in battery and an additional replaceable 18650 battery. This setup meets the demands of prolonged outdoor hunting sessions.
Designed for Hunting and Shooting
The ACE includes essential features for hunting scenarios such as ballistic calculations, auto screen shutdown, recoil-activated video recording, and a shutterless design, making perfect hunting achievable.
- Ballistic Calculation
- Shutterless
- Recoil Activated Video
Outdoor-Friendly Design
The ACE incorporates thoughtful features such as a focus adjuster, charging cover, and a Gallery feature for direct video playback, significantly enhancing user convenience.
Rigorous Testing & High-durability
Crafted from high-strength aluminium alloy, the ACE undergoes rigorous impact resistance testing, ensuring exceptional robustness and durability for years to come.
- IP67
Also Available In:
SPECIFICATIONS
- Model: ACE H50R
- Thermal Sensor, Pixels: 640×512, 12μm
- NETD: ≤15mK
- Frame Rate: 60Hz
- Objective Lens: 50mm F0.9
- Field of View (H×V): 8.8°×7.0° / 15.4x12.3m@100m
- Magnification: 3-24x
- Ocular Zoom: 1-3x
- Detection Range (Target size: 1.7m×0.5m, P(n)=99%): 2600m
- Eye Relief: 50mm
- Exit Pupil Diameter: 8mm
- Diopter: -5 - +5D
- Display Type: 1.03 inch AMOLED
- Display Resolution: 2560x2560
- Battery Type: Built-in battery/4000mAh + Replaceable 18650 battery
- Max. Operating Time (22℃): 7h
- Max. Rangefinder Distance: 1200m
- Ballistic Calculation: √
- Photo/Video Recorder: √
- RAV: √
- Memory Capacity: 64GB
- Wi-Fi/APP: √
- Weight (with battery): 1120g
- Dimension: 365×90×68mm
