FEATURES
Long operation time on a single charge.
Talion is powered with a Pulsar APS 5T interchangeable, rechargeable battery. A single charge guarantees up to 9 hours of battery life (Talion XQ series), which covers the time of active use of the scope for a hunt. The battery cover design helps to accurately determine the correct position and makes it possible to quickly replace a flat battery with a new one in complete darkness by touch alone.
Multi-point prism mount for precise positioning on a rifle.
A mounting prism with multiple screw points to ensure flexibility and convenience when installing a Talion riflescope on various types of rifles. During installation the user can shift the scope along the rifle to the most comfortable viewing position.
All control elements in direct access.
All Talion riflescope controls are placed on the top panel of the eyepiece to simplify access and for the convenience of both right- and left-handed users.
Rapid battery extraction mechanism.
Unique battery cover design with rapid extraction lock ensures fast and flawless battery replacement. Releasing the lock opens and raises the battery cover at the top of the riflescope’s housing for quick access to rechargeable battery.
Focus adjustment with tactile marker set for night-time shot.
The precise focusing adjustment has an integrated fin lever that is set to match the protruding ridge on the housing of Talion riflescope when focusing reaches 70 m (76 yd) mark, the night-time shooting distance. This enables quick and correct focusing, even without looking at the riflescope.
User mode.
Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.
- 3 Sensitivity Amplification Levels - Selection of the signal amplification level combined with new filtration algorithms with fine brightness and contrast adjustments offers the hunter great opportunities for long-range detection of game under diverse weather and temperature conditions. The amplification setting helps to define an animal’s trophy features and ensures clear rendering of objects and background in the field of view.
- Lightweight and Rugged Magnesium Alloy Housing - The Talion’s housing is made of magnesium alloy to ensure great structural strength and retain a light weight. The robust and lightweight metal housing serves also as a heat sink extracting the warmth generated by inner electronics thus making thermal imaging device more sensitive.
- Photo and Video Recording - Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording video. 16 GB of internal memory enables recording many hours of video and tens of thousands of photos.
- Waterproof IPX7 Housing - With an IPX7 waterproof rating, Talion riflescopes work in conditions of high humidity and heavy rain and can withstand half an hour immersion under water to a depth of 1 meter.
- High Calibre Recoil Resistance: 12 gauge, 9.3x64, .375H&H - Talion thermal riflescopes are high impact resistant and can be used with rifled hunting weapons with calibres of 9.3x64, .30-06, .300, .375H&H, etc., as well as with smooth-bore and pneumatic weapons.
- Wi-Fi Integration with iOS and Android Devices. Stream Vision 2 Application - The built-in Wi-Fi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless updating of the device software, transmission of images to a mobile device screen in real time, remote control of digital functions and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.
- 5 Shooting Profiles / 50 Zeroing Distances - Zeroing settings are saved in a shooting profile. Talion memory contains up to five shooting profiles for several types of weapons or cartridges. Each profile can hold up to ten zeroing distances.
- A Selection of 10 Reticule Shapes in 9 Colour Modes - A reticle is electronically displayed in the same plane as the target. The Talion memory contains ten reticle configurations and functions (direct shot type, ballistic, scalable and regular), all available in nine colour options.
- Precision Aiming in the “Picture-in-Picture” Mode - The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.
- Variable Colour Palettes - A choice of 8 colour palettes lets the user observe their field of view more effectively, allowing them to optimise the unit for specific tasks and react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, and Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are best suited to long-range observation at night.
- Mounts - Talion riflescopes come in 4 versions: • Without the mount • Equipped with the Weaver U Mount • Equipped with the Weaver USQD Mount • Equipped with the Weaver LQD Mount
Microbolometer
- Type: Uncooled
- Resolution (Pixels): 384x288
- Pixel Pitch (µm): 17
- NETD (mK): <25
- Frame Refresh Rate (Hz): 50
Optical Specifications
- Lens (mm): F35 F/1.0
- Magnification (x): 2.5-10
- Eye Relief (mm/inch): 50/1.96
- Field of View (H), (°/m@100): 10.7/18.7
- Diopter adjustment (D): -3/+4
- Detection distance (Object of "deer" type), (m/y): 1350 / 1476
Aiming Reticule
- Click Value (mm@100 m – when magnifying), (x): 18 mm – 2.5х; 9 mm – 5х; 4.5 mm – 10х
- Click range (H/V), (mm@100 m): 3600/3600
Display
- Type: AMOLED
- Resolution (Pixels): 1024х768
Operating Features
- Power Supply (V): 3–4.2
- Battery type / Capacity / Rated Output Voltage: Li-Ion Battery Pack АPS 5T / 4900 mAh / DC 3.7 V (removable)
- External Power Supply: 5 V, 9 V (USB Type-C Power Delivery)
- Battery Pack Operating Time at Temp. = 22 °C, hrs** : 9
- Max. Recoil Power on Rifled Weapon (Joules): 6000
- Max. Recoil Power on Smoothbore Weapon (calibre): 12
- Compatible Pulsar Mounts: Weaver U Mount; Weaver USQD Mount; Weaver LQD Mount
- Degree of Protection IP code (IEC60529): IPX7
- Operating Temperature (°С / °F): -25 – +50 / -13 – +122
- Dimensions with an Eyecup (mm/inch): 330x57x67 / 12.99x2.24x2.64
- Weight (with removable battery, without mount), (kg/oz): 0.82 / 28.92
Video Recorder
- Photo / Video Resolution (Pixels): 1024x768
- Video / Photo Format: .mp4 / .jpg
- Built-In Memory: 16 GB
Wi-Fi Channel***
- Frequency: 2.4/5 GHz
- Standard: IEEE 802.11 b/g/n/ac
* Purchased separately.
** Actual battery life may vary depending on the use of Wi-Fi and the built-in video recorder.
*** The reception range may vary depending on various factors: obstacles, other Wi-Fi networks.
