All of the optical surfaces are fully multicoated to limit reflection and enhance light transmission. The duplex crosshair reticle is focused using the dioptric adjustment at the rear of the scope. Shot-corrections of ¼ per click are made by hand without tools. The windage and elevation turrets are protected by screw-down caps. The scope has see-through lens caps to protect the lenses, but still allows you take a shot without removing them.
FEATURES
- Duplex Reticle, 2nd Focal Plane
- 1″ Single-Piece Maintube
- 1/4 MOA Impact Point Correction
- 50 MOA Windage/Elevation Adjustment
- Capped Windage/Elevation Turrets
- Aluminum Alloy Housing
- Fully Multi-Coated Lenses
- Precision-Aligned Optical System
- Water and Fogproof
- Made in Japan
SPECIFICATIONS
| Magnification |
3-12x |
| Objective Lens Diameter |
40mm |
| Maintube Diameter |
25.4 mm |
| Reticle |
Duplex reticle |
| Field of View | 12.7-3.2 m at 100 m |
| Parallax Correction |
91.4 m |
| Eye Relief |
9.65 cm |
| Exit Pupil Diameter |
13.3-3.3 mm |
| Impact Point Correction |
1/4 MOA |
| Windage Adjustment |
50 MOA |
| Weatherproofing |
Waterproof, nitrogen-filled fogproof |
| Dimensions |
30 cm |
| Weight |
360 g |
