FEATURES
The ZEISS LRP S3 first focal plane riflescopes provide the best-in-class total elevation travel. In the world of long-range rimfire competition, the little 22 LR cartridge is frequently pushed beyond its intended limits. In turn, the capabilities and performance of the riflescope are tested at the extreme - with a key limiting factor for many scopes being sufficient elevation travel.
ZEISS LRP S3 4 X 25-50 offers a large field-of-view making it the perfect targeting optic for medium and long-range targets. Its compact and lightweight 34mm main tube is tested to withstand 1,500 g-force of shock over multiple impact cycles.
With a staggering amount of total elevation travel - 160 MOA or 46.5 MRAD for the 4 25-50 model.
LotuTec | Nitrogen filled
- + | +
Water resistance
- 400 mbar
PERFORMANCE
Magnification
- 4 – 25 ×
Effective lens diameter
- 50 mm
Light transmission
- 90%
Exit pupil diameter
- 7.1 – 2.0 mm
Twilight factor
- 11.7 – 35.4
Field of view at 100 m (yds)
- 9.5 – 1.6 m (28.5 – 4.8 ft)
Objective viewing angle
- 5.4° – 0.9°
Diopter adjustment range
- + 3.0 | − 3.0 dpt
Eye relief
- 80 – 90 mm (3.0 – 3.5 ")
Parallax setting
- 15 m – ∞ (16.4 yds – ∞)
Vertical adjustment range at 100 m
- 46.5 MRAD | 160 MOA
Lateral adjustment range at 100 m
- 17.5 MRAD | 60 MOA
Adjustment per click at 100 m
- 0.1 MRAD | 0.25 MOA
Centre tube diameter
- 34 mm
Eyepiece tube diameter
- 45 mm
Objective tube diameter
- 60 mm
PHYSICAL
Operating temperature
- − 25°C | + 56°C (− 13°F | + 133°F)
Length
- 340 mm (13.4 ")
Weight (without inner rail)
- 1040 g (36.7 oz)
