FEATURES
IR Performance, Surprisingly Affordable, and Absolutely Brilliant
01. Enhanced Thermal Clarity with SuperIR
Powered by HIKMICRO SuperIR image enhancement technology, it upscales thermal images from 96 × 96 (9,216 pixels) to 240 x 240 (57,600 pixels) resolution when viewing live with 25 Hz fast image frequency and capturing photos.
02. Dual-camera Thermal Imager
Built-in IR camera and visible camera, allow you to switch 3 image modes (Thermal, Visual, and Fusion). "Fusion" blends key details from a 0.3M Pixels visual camera to the IR image, adding extra detail and clarity.
03. 50° Wide Angle Lens
Scan large areas quickly with the 50° wide angle lens to find issues like air infiltration, water leaks, and insulation issues.
04. Rugged and Durable
Features IP54-rated form factor, passes strict drop tests up to 2 meters (6.56 feet) and comes with a three-year warranty.
Reliable Products that do the Tough Jobs
01. Full-screen Precise and Wide Temperature Measurement
Supports capture of full-screen radiometric images and automatically tracks max/min/centre spots to pinpoint temperature anomalies at a glance. Accurately measures temperatures from -20°C (-4°F) to 550°C (1022°F), with a temperature accuracy up to +/-2°C (+/-3.6°F) or +/-2% of reading.
02. 8 Hrs. Continuous Runtime
Built-in 3350mAh Li-Ion rechargeable battery and thoughtful auto power-off settings (5/10/20 minutes) allow the camera up to 8 hours of continuous operation.
Thoughtful Functions for Your Efficient Workflow
01. Locate with Laser Pointer
Helps show the position of the centre point on actual object.
02. 1-Click IR and Visual Image Storage
Saving visual and thermal images simultaneously in one click allows you efficient workflow and a fast inspection report.
03. 7 Colour Palettes
Offers White Hot, Black Hot, Rainbow, Ironbow, Redhot, Fusion & Above Alarm 7 colour palettes so you can choose the ideal colour scale for your job.
SPECIFICATIONS
Infrared Image
- IR Resolution: 96 × 96 (9,216 pixels)
- NETD: < 50 mK (@ 25 °C, F#=1.0)
- Image Frequency: 25 Hz
- Detector Pitch: 12 μm
- Spectral Range: 7.5 to 14 μm
- Focal Length: 1.35 mm
- F-number: F1.0
- Field of View (FOV): 50° × 50°
- Spatial Resolution (IFOV): 8.89 mrad
- Focus Mode: Focus Free
- SuperIR: 240 x 240 (57,600 pixels)
- Distance to Spot Ratio (D:S): 112:1
- Min. Focus Distance: 0.1m (0.33 ft)
Image Display
- Visual Camera: 640 × 480
- Display: 240 × 320 Resolution, 2.4”LCD Screen
- Image Modes: Thermal/Visual/Fusion
- Colour Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Blue Yellow
Measurement and Analysis
- Object Temperature Range:
- Range -20°C to 150°C (-4°F to 302°F)
- Range 100℃ to 550℃ (212°F to 1022°F)
- Accuracy: Max (±2°C/3.6°F, ±2%) at ambient temperature 25°C (77°F) and object temperature above 0°C (32°F)
- Level and Span Mode: Auto/Manual
- SuperScene Intelligent Detection: Water Leak Scene, Insulation Scene
- Alarm Linkage: Alarm Mode Palettes
- Temperature Measurement Mode: Thermometer mode, Measurements Pre-sets (centre spot, Max spot, in spot, off)
- Alarm: More than, Less than
Data Storage and Communication
- Storage Media: Built-in 4G eMMC (user available storage space is less than the nominal capacity)
- Image Storage Capacity: Approx. 30,000 Images
- Video Storage Capacity: Approx. 10.5 hours
- Radiometric Infrared-Video Streaming (Compressed): Over UVC
General
- USB Interface: USB Type-C
- Battery Type: Rechargeable Li-ion battery
- Battery Operating Time: Approx. 8 hours
- Battery Charging Time: Approx. 3 hours fully charged(Adapter Output：5 V 2 A )
- Protection Level: IP54
- Drop Test Height: 2 m (6.56 ft)
- Working Temperature Range: -10 °C to 50 °C (14 °F to 122 °F)
- Storage Temperature Range: -40 °C to 70 °C (-40 °F to 158 °F)
- Relative Humidity: < 95% non-condensing
- Weight: Approx. 290 g (0.64 lb)
- Dimension: 196 × 117 × 59 mm (7.7 × 4.6 × 2.3 in)
- Tripod Mounting: UNC ¼”-20
- Laser: Yes, Class II
