FEATURES
- First Focal Plane
- 28.88 oz
- 30mm Tube
- Fast Focus Eyepiece
- Side Parallax Adjustment
- Capped Windage Turret
- .1 MIL / .25 MOA Adjustments
RETICLE OPTIONS
TREMOR3™
HORUS GRID
The uniform 0.2 milliradians Horus Grid allows you to easily compensate for bullet drop for any ballistics and density altitude. The solid grid provides numerous precise aiming points for extreme precision, not requiring the user to hold out in space. Additionally, the grid provides fast and accurate Second Shot Corrections.
TIME OF FLIGHT WIND DOTS
Patented Time of Flights Wind Dots provide accurate wind holds in wind speed values (mph, kph, m/s, etc.) to allow for quick and easy holds without a ballistic solver or counting numerous subtensions. These can be calibrated for any ballistics and density altitude providing a universal solution.
HORUS BALLISTICS APP
The easiest way to calibrate wind dots for your ballistics is using the FREE Horus Ballistics App.
HIGHLY-REFINED MIL MARKERS
Refined “Chevron” mil markers throughout the reticle subtend to 0.1 milliradians to provide precise target range estimation. Vertical Chevrons are ideal for milling target height and the horizontal Chevrons for milling target width.
RAPID RANGE BARS
The patented Rapid Range Bars, subtending from 0.5 to 1 milliradians, enable quick estimates of the range to targets of known size. Additionally they can be used with the Accuracy 1st Speed Shooting Formula.
MOVING TARGET HOLDS
Moving Target Holds—the numbered vertical hash marks on both sides of the main horizontal crosshair—indicate leads for targets moving at speeds up to 10 mph. They work for many common calibers from approximately 200-500 yards. Additionally they are used with the Accuracy 1st Speed Shooting formula.
TREMOR3 RETICLE TUTORIAL
TREMOR5
HORUS GRID
The uniform 0.2 milliradians Horus Grid allows you to easily compensate for bullet drop for any ballistics and density altitude. The solid grid provides numerous precise aiming points for extreme precision, not requiring the user to hold out in space. Additionally, the grid provides fast and accurate Second Shot Corrections.
TIME OF FLIGHT WIND DOTS
Patented Time of Flights Wind Dots provide accurate wind holds in wind speed values (mph, kph, m/s, etc.) to allow for quick and easy holds without a ballistic solver or counting numerous subtensions. These can be calibrated for any ballistics and density altitude providing a universal solution.
HIGHLY-REFINED MIL MARKERS
Refined “Chevron” mil markers throughout the reticle subtend to 0.1 milliradians to provide precise target range estimation. Vertical Chevrons are ideal for milling target height and the horizontal Chevrons for milling target width.
TREMOR5 RETICLE TUTORIAL
HORUS H59 - MOA
HORUS GRID
The uniform 1 MOA Horus Grid allows you to easily compensate for bullet drop for any ballistics and density altitude. The solid grid provides numerous precise aiming points for extreme precision, not requiring the user to hold out in space. Additionally, the grid provides fast and accurate Second Shot Corrections.
RAPID RANGE BARS
The patented Rapid Range Bars, subtending from 2 to 5 MOA, enable quick estimates of the range to targets of known size. Additionally, they can be used with the FREE Horus Ballistics App to create extremely fast and accurate MOA-relation tables.
HORUS H59 - MOA REVIEW
SPECIFICATIONS
WEIGHT | 762 g/28.88 oz | |
ILLUMINATION | NON-ILLUMINATED | |
ELEVATION | EXPOSED, SETABLE ZERO | |
WINDAGE | CAPPED | |
FOCAL PLANE | FIRST | |
RETICLE | | TREMOR3™ | TREMOR5™ | H59™ - MOA |
|
MAGNIFICATION RANGE | 5-20x | |
OBJECTIVE LENSE DIAMETER | 50MM | |
INTERNAL ADJUSTMENT RANGE | ELEVATION 17.5 MRAD | |
WINDAGE | 14.5 MRAD | |
CLICK VALUE | 0.1 MRAD | |
PARALLAX ADJUSTMENT | 25 M - ∞ | |
EYE RELIEF | 64-78MM/ 2.52 - 3.7 in | |
EXIT PUPIL DIAMETER |
| 5x: 9.9 mm | 20x: 2.6 mm |
|
DIOPTER RANGE | +/- 2.5 | |
FIELD OF VIEW |
| 5x: 20 ft | 20x: 5.3 ft | 5x: 6.1 m | 20x: 1.62 m |
