FEATURES
With the Patrol 6HD® Gen 2, you can hit the field with confidence. Its ultra-lightweight, low-profile design and 1-6x magnification make it ideal for fast target acquisition in both tactical and competitive scenarios. Built on Leupold’s Professional-Grade Optical System, it delivers exceptional light transmission, glare reduction, and the clarity you can trust in any lighting condition.
The illuminated reticle draws your eye to centre for quick, precise shots, while push-button controls let you adjust brightness instantly.
Lightweight, rugged, and ready for action, this low-power variable optic is built for both-eyes-open speed on the range or in the field.
It’s waterproof, fogproof, and guaranteed to perform for life—so you can focus on the mission, not your optic.
KEY BENEFITS
Leupold’s Professional-Grade Optical System - delivers the light transmission, glare reduction, and resolution professional guides and shooters demand
Eliminates Accidental Dial Movement - with the push-button ZeroLock® system
Provides Repeatable Accuracy and Extended Travel - with competition grade adjustments
Simplifies Mounting and Improves Long-range Accuracy - with the electronic levelling system
Sheds Dirt and Water for Clear, Crisp Images - with Guard-ion™ lens coating
Creates a Visible Aiming Point in Low-light Conditions - with illuminated reticles
Extends Battery Life - with Motion Sensor Technology (MST™)
Quickly Brings the Reticle into Focus - with the fast-focus eyepiece
Allows for Quick Magnification Changes - with the integrated throw lever
Disperses Recoil Energy for Unrivalled Durability - with ultra-lightweight construction
Superior Ruggedness - is verified through Leupold’s Punisher testing process
Waterproof, Fogproof, and Guaranteed to Perform for Life
KEY FEATURES
- Professional-Grade Optical System
- 6:1 Zoom Ratio
- 30mm Maintube
- Fast-focus Eyepiece
- Guard-ion Lens Coating
- Scratch-resistant Lenses
- Competition-Grade Adjustments
- CDS-ZL2 Elevation Dial Available
- High-Definition Performance
- Integrated Throw Lever
- Ultra-lightweight Design
- Waterproof
- Fogproof
- Guaranteed for Life
ILLUMINATED RETICLE FEATURES
- Motion Sensor Technology (MST)
- FireDot Illumination
- Push-button Illumination
- 8 Illumination Settings
- Electronic Reticle Level
RETICLES
Illuminated FireDot Duplex
- Brings New Technology to a Classic Design
- Fiber-optic Powered Red Dot
- Multiple Brightness Settings for Changing Conditions
- FireDot® Technology Brings your eye to the Centre of the Reticle for Quick Target Acquisition
- Broad Range of Shooting Applications
- Rear (second) Focal Plane
- More Details on Leupold's Website
Illuminated CMR2
- The Illum. CM-R2 will measure (subtend) correctly when the riflescope is set to the highest available magnification. The reticles apparent size in the field of view may vary between model's of riflescope
- More Details on Leupold's Website
SPECIFICATIONS
Illuminated FireDot Duplex
- Lens: 24mm
- Magnification: 1 - 6x
- Overall Length: 10.7in
- Maintube Diameter: 30mm
- Weight:
- Illum. FireDot Duplex: 465g / 16.4oz
- Illum. CMR2: 474 / 16.7oz
- Eye Relief:
- Low: 3.7in
- High: 3.8in
- FOV (@100yd):
- Low: 120.9ft
- High: 19.2ft
- Elevation Adjust MOA: 180
- Wind Adjust MOA: 180
- Code:
- Illum. FireDot Duplex: LE185606
- Illum. CMR2: LE185607
- UPC:
- Illum. FireDot Duplex: 030317042066
- Illum. CMR2: 030317042059
