SFP models have capped windage and elevation, while FFP models have exposed locking elevation and capped windage. FFP models also feature a zero stop elevation turret that allows the shooter to have a definite return-to-zero point no matter what distance they have dialed in for. Standard click values for non-MIL reticles are 0.25 MOA, while MIL based reticles feature 0.1 Milradian per click adjustments. Available in several reticle configurations including optional illumination and DichroTech, the 3-18x50 and 3-18x56 are designed with hunters and shooters in mind.
SPECIFICATIONS
MAGNIFICATION | 3 - 18 x | |
OBJECTIVE LENS | 56 mm | |
OBJECTIVE FILTER THREAD | M61x0.75 | |
MAIN TUBE SIZE | 30 mm | |
EXIT PUPIL DIAMETER |
9.5 - 3.1 mm |
|
EYE RELIEF (mm/in) | 100 // 3.94 | |
FIELD OF VIEW (m/100m//ft/100yards) | 11.1-1.9 // 33.3-5.7 | |
FIELD OF VIEW |
6.34 - 1.1 ° |
|
FOCAL PLANE POSITION | 2 | |
DIOPTRIC COMPENSATION |
-2 / 2 D |
|
DAYLIGHT TRANSMISSION |
91 % |
|
TWILIGHT TRANSMISSION |
88 % |
|
TWILIGHT FACTOR |
13 - 31.7 |
|
IMPACT PER CLICK (cm/100m // in/100yds) |
0.7 // 0.26 |
|
WINDAGE AND ELEVATION ADJUSTMENT RANGE (cm/100m // in/100yds) |
262 // 94.3 |
|
PARALLAX CORRECTION |
10 yd - infinity y/n |
|
LENGTH (mm / in) |
368 // 14.5 |
|
WEIGHT (g / oz) |
865 // 30.5 |
