FEATURES
ULTRA CLEAR IMAGE, IMPRESSIVE DETAIL RECOGNITION
- Up to 640x512 Detector
- 12μm Pixel Interval
- F1.0 Large Aperture
ADVANCED APPEARANCE DESIGN FOR GREAT GAME CONVENIENCE
New Focus Knob Design Meets Convenience
The focus knob design makes the focus ring no longer a hassle. This enables a more convenient and natural posture of the hand, and smooth and precise lens focus adjustments with small finger moves.
Magnesium Alloy Design Meets Long-lasting Use
Magnesium alloy design with a lightweight, compact size and an improved stability meets the long-lasting use requirement.
POWERFUL BATTERY PERFORMANCE, GAME NON-STOP
Replaceable and Rechargeable High Capacity Battery
The new battery pack extends working time up to 10h. A spare pack gives the freedom to operate as long as needed even for a full day. Besides, the battery pack performs superior to others, especially in a low-temperature environment.
New Battery Charging Method
The battery is able to charge both in the device and in the charging base. Plug and go.
SOFTWARE REVOLUTION MORE EASILY BRINGS AN ACCURATE VISUAL GAME
Personalized Settings Available to the Suitable Visual Experience
- Brand new UI and friendly quick menu help quickly find frequently used functions.
- DIY brightness and tone adjustment bring playback to the most comfortable level.
Multiple Reticle Profiles
5 reticle groups with 7 colours and 10 reticle types to choose, multiple profiles can be configured and saved for a greater convenience.
Sharing Your Exciting Moments
HIKMICRO Sight is a comprehensive APP designed for outdoor devices. It's an all-in-one solution that supports preview, remote control, browse & download, sharing incredible moments and firmware updates.
MORE ADVANTAGES
- Recoil-activation and audio recording
- Automatic calibration countdown
- IP67 waterproof rated
- Detection range up to 2,600m
- High shock resistance up to 1000g/0.4ms
SPECIFICATIONS
Thermal Module
- Image Sensor: Uncooled Focal Plane Arrays
- Max. Resolution: 384x288
- Frame Rate: 50Hz
- Pixel Interval: 12μm
- NETD: Less than 20mK (25 °C, F#=1.0)
- Response Waveband: 8μm to 14μm
- Lens (Focal Length): 25mm, F1.0
- Detection Range: 1200m
- Focus Mode: Focus Ring
- Min. Focusing Distance: 0.5m
- Magnification: 2.2x-17.6x (8x)
Image Display
- Field of View(H × V), Degrees / m @100m: 10.5° ×7.9°/18.4m × 13.8m
- Display: 1024x768, 0.39 inch, OLED
- Palettes: Black Hot, White Hot, Red Hot, Fusion
- FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
- Exit Pupil: 6mm
- Eye Relief: 45mm
- Diopter (Range): -5 D to 5 D
- Brightness Adjustment: Yes
- Tone Adjustment: Cold, Warm
System
- Record Video: On-board Video Recording
- Capture Snapshot: Yes
- Standby Mode: Yes
- Storage: Built-in EMMC (16 GB)
- PIP: Yes
- Hotspot: Yes
- Hot Track: Yes
- Distance Measurement: Yes
- Audio Recording: Yes
- Recoil-activation Recording: Yes
- Max. Recoil: 1000g/0.4ms
- Zeroing Profiles: 5
Power Supply
- Battery Type: Replaceable and Rechargeable Li-ion Battery Pack
- Battery Operating Time: ≥10.5h (25 °C, with hotspot off)
- Type-C Power Supply: 5V DC, 2 A Supports External Power Supply
General
- Protection Level: IP67
- Dimension: 218.7 mm × 67.1 mm × 68.0 mm
- Weight: 488g without Battery
- Working Temperature: -30 °C to +55 °C (-22 °F to 131°F)
