FEATURES
NETD≤25mK, Dual-Field of View & Laser Rangefinder.
Enhanced Thermal Imaging
Featuring a highly sensitive 12µm detector, NETD≤25mK, and 1024 AMOLED display, the Ares provides exceptional image quality and ensures perfect detail recognition.
Exceptional High Magnification
Up to 5.5X optical zoom without image distortion combined with maximum 5.0X smooth & rapid digital zoom, the Ares brings you exceptional high magnification of up to 27.5X, which largely improves your hunting efficiency and accuracy.
Dual-Field of View
- A wide FOV with a focal length of 20mm can be used for detection;
- A narrow FOV with a focal length of 60mm can be used for identification.
Long Battery Life
With both a built-in and removable batteries, the Ares L gives you total flexibility and up to 12 hours continuous use.
Laser Rangefinder
Ares L includes a 1,000m laser rangefinder for perfect shot placement at any range, allowing users to determinate the distance in various scenarios in single measurements.
Automatic Zeroing
The unique automatic zeroing function is the fastest, simplest zeroing system there is; just take a shot and let the Ares set zero for you.
Non-Shutter Correction Technology
Invisible, background calibration means the screen will never freeze and there is no noisy shutter to alert your quarry.
Long Detection Range
With up to 60mm objective lens and advanced thermal imaging hardware, It boasts exceptional detection range of up to 3,000 meters in complete darkness.
More Advantages
- Wide Options of Colour Palettes - 6 thermal image palettes with comfortable visual experience, to meet with a variety of environments and weather conditions.
- Unique Reticle Features - Pre-loaded with seven different thermal optimized reticles in two different colours and three brightness options, it helps to optimize aiming for specific conditions.
- Real-time APP Notification - The “Smart Thermal” APP can instantly pop up a notification while the monocular detecting and identifying the target to avoid any distraction.
- Picture-in-Picture Function - In picture-in-picture mode, it displays a magnified image at the top-centre of the overall field of view with aligned crosshairs and ½ mil FFP reticle when zooming on an object of interest.
- Zeroing Profiles Management - Store up to 5 zeroing profiles for different guns while displaying zeroing coordinates, distances and type of guns, making it easy to switch guns without having to re-zero.
- IP67 Waterproof - Provided with IP67-rated weatherproof performance, it is protected from heavy rainfall, snow, smoke, smog, or dust.
Also Available in:
SPECIFICATIONS
- Type: Uncooled
- Resolution: 384x288
- Pixel Pitch: 12μm
- NETD: ≤25mK
- Spectral Range: 8-14μm
- Frame Rate: 50Hz
- Objective Lens: 35mm, F1.0
- Field of View: 7.5° x 5.6°
- Magnification: 3.2x
- Digital Zoom: 1x-5x Smooth & Rapid Zoom
- Eye Relief: 50mm
- Exit Pupil: 6mm
- Diopter: -5 ~ ±5D
- Click Range, m@100m (H/V): 3.6m/3.6m
- Reticle: 7
- Reticle Colour: Black & White
- Display Type: AMOLED
- Display Resolution: 1024x768
- Display Size: 0.39 inch
- Colour Palette: 6
- Max. Recoil Power on Rifled Weapon: 6000J
- Mounting Brackets on Weapon: Standard 30mm rings
- RAV: Yes
- Auto Zeroing: Yes
- Manual Zeroing: Yes
- Zeroing Profiles: 5
- Picture-in-picture: Yes
- Image Calibration: Via Lens Cover
- Photo/Video Playback: Yes
- Inbuilt Memory: 16GB
- Type C: Data Transfer
- Wi-Fi: Yes
- Battery Type: Replaceable, 18650 or 18500
- Built-in Battery: 5000mAh, Rechargeable
- Battery Life: 12H
- Operating Temperature: -20°C+50℃
- IP Rating: IP67
- Weight, g: 900
- Size, mm: 397×79×94
