FEATURES
HD Optical System: Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration, and provide outstanding colour fidelity, edge-to-edge sharpness, and light transmission.
Fully Multi-Coated Lenses: Anti-reflective coatings on all air-to-glass surfaces provide increased light transmission for greater clarity and low-light performance.
Fast-Focus Eyepiece: Allows quick and easy reticle focusing.
Aircraft Grade Aluminium: Constructed from a solid block of aircraft-grade aluminium for strength and rigidity.
Low-Glare Matte Black Anodize: Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position.
Waterproof: Designed to withstand harsh weather conditions.
Fogproof: Designed to withstand a wide range of temperatures.
Shockproof: Designed to withstand the highest levels of recoil and impact.
Illuminated Dead-Hold 2A BDC (MOA)
- Illuminated Reticle: Provides precise aiming under low-light conditions.
- Pairs the trusted holdover and windage guidance of the Dead-Hold® BDC with an illuminated floating centre dot for fast, precise aiming in low light. Designed for hunting and shooting at varying distances where holdover estimation matters.
Dead-Hold® BDC (MOA)
- Customized hashmark design helps eliminate guesswork on holdover and windage corrections. Good for hunting and shooting at varying ranges, where estimating holdover is a concern.
Muzzleloader BDC (MOA)
- Specially calibrated for the slower velocities of modern muzzleloaders. This reticle ensures accurate holds over distance, giving you confidence in longer shots.
Straight-Wall BDC (MOA)
- Designed for hunters using straight-wall cartridges like .450 Bushmaster, 350 Legend, and .45-70 Government. Its Straight-Wall BDC reticle delivers accurate holds at longer ranges, so you can maximize your performance.
V-Plex (MOA)
- A simple “point-and-shoot” choice, reticles like the V-Plex are frequently a hunter’s first. And, depending on where and how you hunt, they could easily be all you’ll ever need.
SPECIFICATIONS
- Magnification: 3-9x
- Objective Lens Diameter: 40 mm
- Focal Plane: Second Focal Plane
- Reticles:
- Illuminated Dead-Hold® 2A BDC (MOA)
- Dead-Hold® BDC (MOA)
- Muzzleloader BDC (MOA)
- Straight-Wall BDC (MOA)
- V-Plex (MOA)
- Eye Relief: 3.8"
- Field of View: 37.2' - 12.4' @ 100 yds.
- Turret Style: Capped
- Tube Size: 1 inch
- Adjustment Graduation: 1/4 MOA
- Travel Per Rotation: 15 MOA
- Max Elevation Adjustment: 72 MOA
- Max Windage Adjustment: 72 MOA
- Parallax Setting: 100 yds.
- Length: 12.5"
- Weight:
- Illuminated Dead-Hold® 2A BDC: 17.1 oz.
- Dead-Hold® BDC: 16.2 oz.
- Muzzleloader BDC: 16.2 oz.
- Straight-Wall BDC: 16.2 oz.
- V-Plex: 16.2 oz.
