FEATURES
Built for hunters and competitors, where split-second decisions make or break success. Talon® HD 10K puts the Vortex's top-tier glass, extreme-range performance, and real-time ballistic data in one tool you can count on. Run it solo or pair with Vortex Relay™ devices for seamless data flow across your setup. From spotting your target to taking the shot, Talon® HD keeps you fast and focused - no matter the distance.
Ranging Modes
- Line of Sight (LOS): Displays the actual line of sight range.
- Horizontal Component Distance (HCD): Displays the slope angle compensated distance to the target.
- Ballistics (BAL): Displays the actual line of sight range and wind/drop solution.
- SCAN Feature: Displays continuous distance readings while panning across a landscape.
Target Modes
- Normal Mode: The standard mode providing the target's range with the strongest range result. Recommended for most situations.
- First Mode: Displays the closest distance when ranging. Ideal for ranging a smaller target in front of other larger or more reflective objects.
- Last Mode: Displays the farthest distance when ranging. Ideal for ranging a specific target behind a group of objects like brush, trees, rocks, etc.
- Extended Laser Range (ELR) Mode: Ideal for ranging targets at extreme distances. A slightly longer response time allows greatly for extended range distances.
- Rain/Fog Mode: Ideal for ranging in adverse conditions, such as rain, snow, fog, or dust. Helps the rangefinder return accurate readings despite poor visibility.
10,000-Yard Capability
- For ranging shots, planning stages and stalks.
HD Optical System
- Premium glass and optical technology for long-range clarity.
In-Display Wind/Drop Solutions
- Provided by integrated GeoBallistics® Solver.
Active Matrix Red OLED Display
- Intuitive, customizable, auto-levelling.
Customizable Ballistic Profiles
- Use presets or load your own for any shooting setup.
On-Board Environmental Sensors
- Real-time temperature, pressure, humidity, compass bearing, and inclination.
Wind Bearing Capture Mode
- Lock in wind speed and direction for accurate shots.
Vortex Relay™ Connectivity
- Connects to share real-time ballistic, environmental, and rifle-specific data across a suite of devices.
Integrated GeoBallistics® Solver
- Equipped with the accurate GeoBallistics® Solver backed by a full, up-to-date bullet library.
Built-in Range Card Generator
- Ability to create and save up to ten range cards with drop and wind corrections.
XR™ Plus Lens Coatings
- Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
Adjustable Eyecups
- Twist up and down for comfortable viewing with or without eyeglasses.
Centre Focus Wheel
- Adjusts the focus of both binocular barrels at the same time.
Locking Diopters
- Adjusts for differences in a user's eyes.
ArmorTek®
- Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
Rubber Armor
- Provides a secure, non-slip grip, and a durable external protection.
Nitrogen Gas Purged
- Gas purged and O-ring sealed for superior fogproof and waterproof performance in the most extreme conditions.
Waterproof
- Designed to withstand harsh weather conditions.
Fogproof
- Designed to withstand a wide range of temperatures.
Shockproof
- Designed to withstand the highest levels of impact.
Tripod Adaptable
- Allowing use on a tripod or car window mount. Tripod adapter may be required.
SPECIFICATIONS
10x42mm
- Magnification: 10x
- Objective Lens Diameter: 42mm
- Eye Relief: 18.5mm
- Angular Field of View: 6.1°
- Linear Field of View: 321' @ 100 yds.
- Range Reflective (yards): Up to 10,000 yds.
- Range Tree (yards): Up to 4000 yds.
- Range Deer (yards): Up to 2400 yds.
- Min Range: 10 yds.
- Height: 6.3"
- Width: 5.5"
- Weight: 40.8 oz.
12x50mm
- Magnification: 12x
- Objective Lens Diameter: 50mm
- Eye Relief: 18.5mm
- Angular Field of View: 5.2°
- Linear Field of View: 272' @ 100 yds.
- Range Reflective (yards): Up to 10,000 yds.
- Range Tree (yards): Up to 4200 yds.
- Range Deer (yards): Up to 2600 yds.
- Min Range: 10 yds.
- Height: 7.2"
- Width: 5.6"
- Weight: 46.8 oz.
RETICLE
ACTIVE MATRIX RED OLED DISPLAY
A fully customizable, auto-levelling, and intuitive interface that displays wind/drop solutions and range data seamlessly, allowing shooters to make fast adjustments without distraction.
