FEATURES
The Conquest V4 line of high-performance riflescopes combines the tried-and-true ZEISS optics concept with a rugged and functional design. The easy to read markings and the huge selections of different reticles available allow for extremely precise and extreme accurate shots.
- Outstanding Light Transmission and Optical Clarity
- Precision, User-friendly Mechanics
- Rugged Versatility with Smart Zoom Range
Exceptional Low-Light Performance
The large 56 mm objective lens ensures maximum light transmission, giving hunters a clear, bright image at dusk, dawn, and even into the night.
Illuminated Reticle for Precision
The illuminated reticle provides reliable aiming in poor lighting, guaranteeing accuracy when visibility is at its toughest.
The ZEISS Conquest V4 riflescope series is built to give hunters a true advantage - combining legendary ZEISS optics, rugged durability, and versatile performance in any environment. With up to 90% light transmission, advanced T* lens coatings, and LotuTec protection, the V4 delivers razor-sharp, high-contrast images even in low light or harsh weather.
Engineered to handle heavy recoil, rough terrain, and extreme conditions, these riflescopes are as tough as your toughest hunts. Add optional ballistic reticles for rapid holdover corrections - no turret adjustments needed – and you get unmatched accuracy and flexibility in the field.
4x Zoom Range
The 4x zoom range allows hunters to perfectly recognize details and offers an excellent overall view for a safe and accurate shot.
Reticle Illumination
The reticle illumination can be adjusted finely and accurately over 10 different levels, allowing hunters to precisely adjust the brightness to any situation and time of day – for the perfect shot.
90% Light Transmission
Higher definition glass produces 90% to-the-eye light transmission, great low-light performance and excellent target resolution across the entire magnification range.
A Clear View, Whatever the Weather
With dependable equipment, hunters can confidently face any weather conditions. That's why ZEISS developed LotuTec®, a lens coating for binoculars and scopes that ensures clear vision for every hunting adventure, regardless of the conditions.
Stable and Shot-Proof
The ZEISS V8, ZEISS Victory HT, ZEISS Conquest V6, and ZEISS Conquest V4 riflescopes are all ideally suited for use with "clip-on" attachments, ensuring reliable performance and repeatability even under heavy loads, enhancing hunting capabilities.
ZEISS T* Coating
ZEISS T* coating guarantees brilliant, high-contrast images, especially in adverse light conditions and twilight. However, there is no specific formula for building up the layers; instead, it is a technology constantly adjusted to suit new glass materials and requirements, varying from lens to lens.
RETICLE
Reticle 20 (Z-Plex) - Non-Illuminated
The very fine reticle 20 is located in the second image plane. During daytime hunting, it enables you to shoulder your rifle and aim extremely precisely, even at long distances. The transition from the bars to the fine lines in the centre is arrow-shaped in the reticle 20. This gives you the ability to aim especially precisely at small targets.
SPECIFICATIONS
- Magnification: 3 – 12 x
- Focal Plane: Second
- Reticle Options: 60 | 20
- Light Transmission: 90 %
- Effective Lens Diameter: 27.7 – 56 mm
- Exit Pupil Diameter: 9.2 – 4.7 mm
- Twilight Factor: 9.1 – 25.9
- Field of View at 100 m (yds): 12.7 – 3.2 m (38 – 10 ft)
- Objective Viewing Angle: 7.2° – 1.8°
- Diopter Adjustment Range: + 2.0 | − 3.0 dpt
- Eye Relief: 90 mm (3.54")
- Parallax Setting: 91.4 m
- Elevation Adjustment Range at 100 m: 200 cm
- Windage Adjustment Range at 100 m: 200 cm
- Adjustment per Click at 100 m: 1/4 MoA (0.7 cm | 100 m)
- Main Tube Diameter: 30 mm
- Eyepiece Tube Diameter: 44 mm
- Objective Tube Diameter: 62 mm
- LotuTec: +
- T* Coating: +
- Nitrogen Filled: +
- Waterproof: 400 mbar
- Operating Temperature: − 25 °C | + 50 °C (− 13 °F | + 122 °F)
- Length: 368 mm (14.5")
- Weight (Without Inner Rail): 610 g (21.5 oz)
- Weight (With Inner Rail): –
