It also has the ability to cant, which can be locked and secured with the adjustable lever.
Our quick detach rail mount is simple, quick, and very secure; it attaches to a 1913 Picatinny rail and mounts in seconds without the need to use extra tools for tightening. Our ratcheted leg extension design allows the shooter to quickly adjust to 9 different heights without having to align each leg equally. The spring-loaded leg extension retracts quickly with a one-button retraction lever. The retracted leg height of 6 inches extends to a full open position of 10 inches with 8 other positions in-between.
To engage or adjust leg position, simply pull the spring-loaded leg downward to move each leg independently. Leg position can be deployed to 90° or 45°, locking securely into 4 positions.
Specifications:
| Materials |
6061 T6 Aluminum alloy / High strength steel hardware |
| Min. Height (Legs at 45°) |
5.5” / 140 mm |
| Min. Height (Legs at 90°) |
7.25″ / 184.15 mm |
| Max. Height (Legs at 90°) |
10.0” / 254.0 mm |
| Min. Stance (Legs at 45°) |
11.0″ / 279.4 mm |
| Max. Stance (Legs at 90°) |
17.25″ / 438.15 mm |
| Closed Position Width |
5.0″ / 127 mm |
| Closed Position Length |
9.0” / 228.6mm |
| Weight |
23.92 oz |
| Color |
Flat Black |
| Coating |
Type III ( MIL-SPEC ) Hard Anodize |
